Types of Grinding

Grinding

There are many forms of grinding, but the four major industrial grinding processes are:

cylindrical grinding

A cylindrical grinder is used for shaping the outside of a workpiece. These machines accept workpieces in a variety of shapes as long as they can be rotated through a central axis. In a cylindrical grinder, both the workpiece and grinding wheel are simultaneously rotated. Outside diameter grinders, internal diameter grinders, and centerless grinders are all types of cylindrical grinders.



internal grinding

Internal grinding is used to grind the internal diameter of the workpiece. Tapered holes can be ground with the use of internal grinders that can swivel on the horizontal.



centerless grinding

Centerless grinding is when the workpiece is supported by a blade instead of by centers or chucks. Two wheels are used. The larger one is used to grind the surface of the workpiece and the smaller wheel is used to regulate the axial movement of the workpiece. Types of centerless grinding include through-feed grinding, in-feed/plunge grinding, and internal centerless grinding.



surface grinding

Surface grinding uses a rotating abrasive wheel to remove material, creating a flat surface. The tolerances that are normally achieved with grinding are ±2×10−4 inches (5.1 μm) for grinding a flat material and ±3×10−4 inches (7.6 μm) for a parallel surface.
